4-6-2T Class H16 LSWR/SR Profile and Models

The LSWR H16 class were five 4-6-2 tank locomotives designed by Robert Urie for the London and South Western Railway (LSWR) in 1921–1922. They were the last new design for the LSWR and their only Pacific-type design. As part of the project to construct a marshalling yard at Feltham in West London, Urie produced two locomotive designs, the G16 "Black Tanks" to shunt the new yard, and the H16 "Green Tanks" to work transfer freights to the London area yards of the other railway companies. he Southern Railway painted the H16 class in passenger green paint, rather than goods engine black. All five engines were passed to British Railway who renumbered them 30516–30520. All were withdrawn in 1962, and scrapped. (Information provided via Wikipedia)
Type of Locomotive	Steam
Builder	LSWR Eastleigh Works
Build Date	1921 to 1922
Total Built	5
Tractive Effort	28,200 lbf
Wheel Configuration	4-6-2T
Operated By	London & South Western Railway Southern Railway British Railways
Main Duties	Mixed Traffic
In Service Until	1962
Surviving Examples	0

Products awaiting categorisation

Scale	Brand	Image	Construction Type	DCC Capability	Product Code	Product Title	Livery
OO Gauge (1:76 Scale)	Millholme Models		Requires assembly	Not set	MM21MM View	Urie class H16 4-6-2T - kit	Awaiting Categorisation
